Integrated amplifiers — Arcam A5+
Description, images, technical data and specifications
Arcam A5+
Image source — © Arcam
Arcam A5+ is an integrated Class AB amplifier with a power of 2×75 watts (8 ohms), Bluetooth aptX Adaptive, MM phono corrector, digital—to-analog inputs and clear detailed sound.
Specifications
Model name
A5+
Type
Integrated Amplifier with Bluetooth and Auracast
Analog inputs (balanced)
N/A
Analog inputs (single-ended)
3 + 1 (Phono)
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
N/A
Input impedance (single-ended) (Ω)
N/A
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
D/A conversion
Yes
Phono MM/MC current-sensing input impedance (Ω)
40 000
Output power (8Ω) (W)
50
Output power (4Ω) (W)
75
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Signal to Noise Ratio (dB)
106
Total Harmonic Distortion + Noise (%)
0.003
Damping factor
N/A
Dimensions (mm)
431 x 344 x 83
Weight (kg)
8.0
