Cartidges — OTTA Mandolin

Description, images, technical data and specifications

OTTA Mandolin
Image source — © OTTA

The body of the new OTTA Mandolin MC cartridge is CNC machined from red sandalwood. The wooden elements cover the aluminum base motor with minimal tolerances. The head is equipped with a patented magnetic system with an increased magnetic gap and samarium-cobalt magnets.

Specifications

  • Model name

    Mandolin

  • Type

    MC

  • Stylus

    Elliptical diamond

  • Body

    Red sandalwood

  • Cantilever

    Ruby

  • Coils

    Pure Iron Cross Coil

  • Output voltage (mV@5cm/sec)

    0.35

  • Frequency response low +/- 3dB (Hz)

    20

  • Frequency response high +/- 3dB (Hz)

    25000

  • Internal impedance (Ohm)

    5

  • Channel separation (dB / 1,000 Hz)

    N/A

  • Compliance (×10-6cm/dyne at 100Hz)

    15

  • Recommended load (Ohm)

    100 - 470

  • Recommended tonearms

    Medium

  • Weight (g)

    8.4

  • Official link

    none

OTTA Mandolin
