Cartidges — Clearaudio Concept V2

Description, images, technical data and specifications

Clearaudio Concept V2
Image source — © Clearaudio

Clearaudio Concept V2 — MM cartridge with aluminum body and cantilever, elliptical needle, output voltage 3.3 mV, range 20-20, 000 Hz, weight 8.6 g and downforce 1.9–2.5 g; provides clear and detailed sound.

Specifications

  • Model name

    Concept V2

  • Type

    MM

  • Stylus

    Elliptical

  • Body

    Aluminium

  • Cantilever

    Aluminium

  • Coils

    N/A

  • Output voltage (mV@5cm/sec)

    3.3

  • Frequency response low +/- 3dB (Hz)

    20

  • Frequency response high +/- 3dB (Hz)

    20 000

  • Internal impedance (Ohm)

    N/A

  • Channel separation (dB / 1,000 Hz)

    20

  • Compliance (×10-6cm/dyne at 100Hz)

    15 μ/mN

  • Recommended load (Ohm)

    47 000

  • Recommended tonearms

    N/A

  • Weight (g)

    8.6

  • Official link

    https://clearaudio.de/en/products/cartridges-mm-v2.php
