Clearaudio CONCEPT MC SIGNATURE
Image source — © Clearaudio

The Clearaudio Concept MC Signature is an MC cartridge with a Micro Line diamond needle and a harrow cantilever, with an output of 0.4 mV, a frequency range of 20-20,000 Hz, an impedance of 11 ohms and a downforce of 2.2 g; it features detailed, neutral and spatial sound.

Specifications

  • Model name

    CONCEPT MC SIGNATURE

  • Type

    MC

  • Stylus

    Micro Line

  • Body

    Aluminium-magnesium alloy with ceramic surface layer

  • Cantilever

    Boron

  • Coils

    OFC - copper

  • Output voltage (mV@5cm/sec)

    0.4

  • Frequency response low +/- 3dB (Hz)

    20

  • Frequency response high +/- 3dB (Hz)

    20 000

  • Internal impedance (Ohm)

    11

  • Channel separation (dB / 1,000 Hz)

    >30

  • Compliance (×10-6cm/dyne at 100Hz)

    9 μ/mN

  • Recommended load (Ohm)

    N/A

  • Recommended tonearms

    N/A

  • Weight (g)

    8

  • Official link

    https://clearaudio.de/en/products/cartridges-mc-concept_mc.php
