Power amplifiers stereo — Rotel RB-1552 MkII

Description, images, technical data and specifications

Rotel RB-1552 MkII
Image source — © Rotel

The Rotel RB-1552 MkII amplifier operates in class A/B and outputs 120 watts into each of the two channels. Its design is built with high power and reliability, but at the same time, the main focus is on the ability to extract the finest nuances from even the most complex musical compositions. The fanatical attention of Rotel engineers to the smallest details means that the total amount of their efforts becomes more than its components – this is the company's Balanced Design Concept.

Specifications

  • Model name

    RB-1552 MkII

  • Input sensitivity (mV)

    2.5 (XLR) + 1.5 (RCA)

  • Input impedance (balanced) (Ω)

    100 000

  • Input impedance (single-ended) (Ω)

    12 000

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • Max current (A)

    N/A

  • Output power (8Ω) (W)

    130

  • Output power (4Ω) (W)

    185

  • Gain (dBu)

    22.5 (XLR) + 26.5 (RCA)

  • Frequency response low +/- 3dB (Hz)

    20

  • Frequency response high +/- 3dB (Hz)

    20 000

  • Signal to Noise Ratio (dB)

    120

  • Total Harmonic Distortion + Noise (0% global feedback) (%)

    N/A

  • Total Harmonic Distortion + Noise (100% global feedback) (%)

    <0.03

  • Max power consumption (W)

    400

  • Damping factor

    450

  • Dimensions (mm)

    431 × 144 × 339

  • Weight (kg)

    12.4

  • Official link

    https://rotel.com/product/rb-1552-mkii
