Power amplifiers mono — Emotiva XPA-1 Gen3

Specifications

• Model name

  XPA-1 Gen3

• Input sensitivity (mV)

  1710

• Input impedance (balanced) (Ω)

  33 000

• Input impedance (single-ended) (Ω)

  23 500

• Output impedance (balanced) (Ω)

  N/A

• Output impedance (single-ended) (Ω)

  N/A

• Max current (A)

  N/A

• Output power (8Ω) (W)

  300

• Output power (4Ω) (W)

  600

• Gain (dBu)

  29

• Frequency response low +/- 3dB (Hz)

  5

• Frequency response high +/- 3dB (Hz)

  80 000

• Signal to Noise Ratio (dB)

  >117

• Total Harmonic Distortion + Noise (0% global feedback) (%)

  N/A

• Total Harmonic Distortion + Noise (100% global feedback) (%)

  < 0.005

• Max power consumption (W)

  100

• Damping factor

  > 500

• Dimensions (mm)

  432 × 203 × 483

• Weight (kg)

  15,2

• Official link

  https://emotiva.com/products/xpa-1-gen3
