Integrated amplifiers — Lyngdorf TDAI-2210

Description, images, technical data and specifications

Lyngdorf TDAI-2210
Image source — © Lyngdorf

"TDAI" stands for True Digital Amplifier Integrated. The Lyngdorf TDAI-2210 amplifier path is fully digital up to the acoustic terminals, without analog conversion that could distort the sound. The digital signal directly controls the acoustics, and the volume knob adjusts the gain in the output circuit.

Specifications

  • Model name

    TDAI-2210

  • Type

    Integrated Amplifier with streamer

  • Analog inputs (balanced)

    N/A

  • Analog inputs (single-ended)

    2

  • Input sensitivity (mV)

    N/A

  • Input impedance (balanced) (Ω)

    N/A

  • Input impedance (single-ended) (Ω)

    N/A

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • D/A conversion

    Yes

  • Phono MM/MC current-sensing input impedance (Ω)

    N/A

  • Output power (8Ω) (W)

    2 x 105

  • Output power (4Ω) (W)

    2 x 210

  • Gain (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    20

  • Frequency response high +/- 3dB (Hz)

    20 000

  • Signal to Noise Ratio (dB)

    N/A

  • Total Harmonic Distortion + Noise (%)

    0.05

  • Damping factor

    N/A

  • Dimensions (mm)

    325 x 102 x 300

  • Weight (kg)

    4.8

  • Official link

    https://lyngdorf.steinwaylyngdorf.com/lyngdorf-tdai-2210/
