Cartidges — MoFi Electronics ULTRAGOLD MC PHONO

Description, images, technical data and specifications

MoFi Electronics ULTRAGOLD MC PHONO
Image source — © MoFi Electronics

The MoFi Electronics UltraGold MC is a top—of-the-line MC cartridge created in Japan and customized by Allen Perkins (Spiral Groove). Its main feature is a Nude Shibata diamond needle holder and a boron cantilever, which gives a very wide frequency range (20-35,000 Hz), excellent dynamics, clear treble and deep, rich bass.

What is it?

Ask AI to scan specialized sites and forums, evaluate the impressions of using the product, its advantages and disadvantages and get a summary.

Specifications

  • Model name

    ULTRAGOLD MC PHONO

  • Type

    MC

  • Stylus

    Shibata

  • Body

    aluminum

  • Cantilever

    boron

  • Coils

    pure Copper by Ohno Continuous

  • Output voltage (mV@5cm/sec)

    0.4

  • Frequency response low +/- 3dB (Hz)

    20

  • Frequency response high +/- 3dB (Hz)

    35 000

  • Internal impedance (Ohm)

    12

  • Channel separation (dB / 1,000 Hz)

    N/A

  • Compliance (×10-6cm/dyne at 100Hz)

    10

  • Recommended load (Ohm)

    ≥ 100

  • Recommended tonearms

    N/A

  • Weight (g)

    7.3

  • Official link

    https://www.mofielectronics.com/products/mofi-electronics-ultragold-mc-phono-cartridge
