Cartidges — Air Tight PC-1 coda

Description, images, technical data and specifications

Air Tight PC-1 coda
Image source — © Air Tight

The base of the cartridge is made of A7075 aluminum alloy, which provides precise bass and a clean sound stage, while the body is made of A6063 aluminum. The needle holder is boron, a needle with an elliptical "semi-line contact" sharpening is attached to it. The downforce is 2-2.2 g. The terminals are coated with rhodium.

Specifications

  • Model name

    PC-1 coda

  • Type

    MC

  • Stylus

    Semi-line contact

  • Body

    N/A

  • Cantilever

    boron

  • Coils

    N/A

  • Output voltage (mV@5cm/sec)

    0.5

  • Frequency response low +/- 3dB (Hz)

    N/A

  • Frequency response high +/- 3dB (Hz)

    N/A

  • Internal impedance (Ohm)

    1.7

  • Channel separation (dB / 1,000 Hz)

    N/A

  • Compliance (×10-6cm/dyne at 100Hz)

    N/A

  • Recommended load (Ohm)

    N/A

  • Recommended tonearms

    N/A

  • Weight (g)

    12.7

  • Official link

    http://www.airtight-anm.com/components/pc1coda.html
