The Aerofon is a floorstanding horn loudspeaker from AER, a German company that has built loudspeakers since 1985. It combines full-range drivers by Filip Keller with horn cabinets by Markus Boldyreff, and AER presents it as the result of more than 40 years of work on both. This model is the smaller of the two Aerofon cabinets, sold as the Essenz. Each cabinet is offered with an entry-level BD E or a top BD 5 driver, and other AER material lists the two versions as Aerofon econ and Aerofon essence.
Key specs that matter
Each cabinet measures 1,510 x 340 x 410 mm (H x W x D). With the BD E driver, designed from scratch for this range, AER specifies an efficiency of 102 dB (1 W/1 m), and with the BD 5 the figure is 116 dB. The published frequency range is 35 Hz - 80 kHz, while the launch announcement of the two cabinets gives 38 Hz as the lower limit of the Essenz, 3 Hz above the larger model. Launch prices were EUR 25,000 per pair with the BD E and EUR 70,000 per pair with the BD 5. An upgrade from BD E to BD 5 is available at any time for the price difference between the drivers. The enclosure is tempered acrylic glass in white, black or special colours on request.
Engineering and use context
AER describes the Aerofon as an analogue horn design. Its enclosure is a back-loaded horn, and the driver sits in the opening from which the low frequencies leave the cabinet. Tempering is part of the process AER uses to optimise the acrylic glass for acoustic use. Filip Keller reworked both the BD E and the BD 5 for the Aerofon range, and the BD 5 has the latest edition of his suspension design. No crossover network is fitted, so the full-range driver covers the whole band alone.
Pairing
AER intends the Aerofon for tube amplifiers. The amplifier connects directly to the single full-range driver with no filter parts in between.
Alternatives
The AER Aerofon Experienz is the larger cabinet of the same range, 1,900 mm tall on a 540 x 600 mm base and specified down to 35 Hz.
