Headphones amplifiers — Luxman P-750u

Description, images, technical data and specifications

Luxman P-750u
Image source — © Luxman

Luxman P-750u is a top—of-the-line headphone amplifier with balanced circuitry. Unlike most similar devices, this device is made in a metal case with a standard width for Hi-Fi components, which will allow it to perfectly fit into an existing set of audio equipment. At the same time, the small height will ensure easy installation even in the case of limited free space in the rack.

What is it?

Ask AI to scan specialized sites and forums, evaluate the impressions of using the product, its advantages and disadvantages and get a summary.

Specifications

  • Model name

    P-750u

  • Maximum Power, 32 Ohms (mW RMS per channel)

    1000 (RCA) + 4000 (XLR)

  • Maximum Power, 50 Ohms (mW RMS per channel)

    N/A

  • Maximum Power, 300 Ohms (mW RMS per channel)

    N/A

  • Maximum Power, 600 Ohms (mW RMS per channel)

    53 (RCA) + 213 (RCA)

  • Frequency response low +/- 3dB (Hz)

    10

  • Frequency response high +/- 3dB (Hz)

    170 000

  • Gain (dBu)

    N/A

  • THD (% at 1V RMS, 300 ohms)

    0.003 (RCA) + 0.002 (XLR)

  • Signal to Noise Ratio (dB)

    N/A

  • IMD (%, CCIR, 300 Ohms)

    N/A

  • Crosstalk (dB, 20Hz-20KHz, 300 Ohms)

    N/A

  • Output Impedance (Ohms)

    N/A

  • Dimensions (mm)

    440 x 92 x 400

  • Weight (g)

    13.3

  • Official link

    https://www.luxman.com/product/detail.php?id=7
