SOtM sPS-1000
Image source - (c) SOtM

The sPS-1000 is a DC linear power supply from SOtM, the Korean maker of music servers, USB cards and clock modules. It is intended for audio devices that use DC power, and SOtM now lists it among its discontinued products. American buyers paid USD 1,000 at launch, and the standard version cost EUR 1,299 in Italy.

Key specs that matter

Three DC outputs, labelled High, Mid and Low Level, sit on the rear panel and can be used at the same time. Each one has four selectable voltages. The High Level output gives 18, 19, 20 or 21 V at 4 A max, the Mid Level output 9, 10, 11 or 12 V at 2 A max, and the Low Level output 5, 5.5, 6 or 7 V at 1 A max. AC input is 220 - 230 V or 110 - 115 V, 50/60 Hz, at 2 A or 4 A. The case measures 360 x 68 x 245 mm and weighs 8 kg or more.

Engineering and use context

SOtM designed the sPS-1000 to operate with linear circuits only, with no digital circuits inside, so the unit generates no digital high-frequency noise. Ultra Low Noise Regulator circuits reduce the residual noise of the linear stages, and a built-in noise filter blocks noise arriving from the AC mains. Protection includes an output short protection circuit and an over-temperature protection circuit. According to SOtM, the audio components were chosen through a number of experiments.

Its High Level output is intended for digital media players such as the sMS-1000SQ and for low-power PCs. Mid Level suits most audio devices, for example the sDP-1000EX, and Low Level is for small devices such as the tX-USBexp card. SOtM also names Wi-Fi routers, turntables and phono stages as possible loads. Voltage is set at a switch knob with a small flat-head screwdriver, and on request SOtM can modify the standard voltage and current for a specific device. The front panel has a DC output on/off switch and an operating indicator, with the AC power switch on the rear. A 30 cm copper DC cable with an ID2.1-ID2.5 plug is supplied, and optional cables are offered in 30, 50 or 100 cm lengths, including stranded 7N UPOCC copper and silver versions.

Pairing

The High Level output matches the +19 V input of the SOtM sMS-1000SQ server. Any DC-powered device whose voltage and current fall inside one of the three output ranges can be connected. The correct DC plug for each device is required.

Alternatives

The SOtM sPS-500 is a smaller single-output DC power supply with 7, 9, 12 or 19 V selectable.
