Preamplifiers — PrimaLuna EVO 100-3

Description, images, technical data and specifications

PrimaLuna EVO 100-3
Image source — © PrimaLuna

PrimaLuna Evolution 100 Power Black is a vacuum tube sound power amplifier. This model will be appreciated by music lovers, for whom the best sound quality of the audio system is a priority. The power of the tube amplifier in stereo mode is 40 watts per channel. In mono mode, this value can reach 82 watts.

What is it?

Ask AI to scan specialized sites and forums, evaluate the impressions of using the product, its advantages and disadvantages and get a summary.

Specifications

  • Model name

    EVO 100-3

  • Analog inputs (balanced)

    N/A

  • Analog inputs (single-ended)

    4

  • Analog outputs (balanced)

    N/A

  • Analog outputs (single-ended)

    1

  • Gain (dBu)

    10.8

  • Input sensitivity (mV)

    580

  • Output voltage (V)

    N/A

  • Input impedance (balanced) (Ω)

    N/A

  • Input impedance (single-ended) (Ω)

    220 000

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    2800

  • Maximum output level (balanced) (dBu)

    N/A

  • Maximum output level (single-ended) (dBu)

    N/A

  • Volume control range (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    15

  • Frequency response high +/- 3dB (Hz)

    80 000

  • Signal to Noise Ratio (SNR, unweighted) (dB)

    93

  • Total Harmonic Distortion + Noise (THD+N) (%)

    <0.2

  • Dimensions (mm)

    405 x 280 x 190

  • Weight (kg)

    14

  • Official link

    https://www.primaluna.nl/tube/pre/primaluna-evo-100-tube-preamplifier/
