Power amplifiers stereo — Anthem STR Power Amplifier
Description, images, technical data and specifications
Anthem STR Power Amplifier
Image source — © Anthem
Specifications
Model name
STR Power Amplifier
Input sensitivity (mV)
2100
Input impedance (balanced) (Ω)
15 000
Input impedance (single-ended) (Ω)
10 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
400
Output power (4Ω) (W)
800
Gain (dBu)
29
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Signal to Noise Ratio (dB)
121
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
0.0007
Max power consumption (W)
1100
Damping factor
N/A
Dimensions (mm)
172 × 432 × 470
Weight (kg)
27.3
Official link
