Power amplifiers stereo — Gold Note PA-1175 MkII
Description, images, technical data and specifications
Gold Note PA-1175 MkII
Image source — © Gold Note
The device is a power amplifier, where 4 pairs of matched transistors for each channel work in the output stage. The power is up to 200 watts per channel, and in bridge mode, if the device is used as a monoblock, it increases to 520 watts! Such indicators require the use of a special power transformer, and it is here.
Specifications
Model name
PA-1175 MkII
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
47 000
Input impedance (single-ended) (Ω)
47 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
200
Output power (4Ω) (W)
N/A
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
1
Frequency response high +/- 3dB (Hz)
100 000
Signal to Noise Ratio (dB)
110
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
<0.01
Max power consumption (W)
N/A
Damping factor
250
Dimensions (mm)
430 x 135 x 370
Weight (kg)
20.5
Official link
