Power amplifiers mono — PS Audio M1200 Amplifier
Description, images, technical data and specifications
PS Audio M1200 Amplifier
Image source — © PS Audio
Specifications
Model name
M1200 Amplifier
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
100 000
Input impedance (single-ended) (Ω)
50 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
<0.007
Max current (A)
N/A
Output power (8Ω) (W)
600
Output power (4Ω) (W)
1200
Gain (dBu)
30.5
Frequency response low +/- 3dB (Hz)
10
Frequency response high +/- 3dB (Hz)
45 000
Signal to Noise Ratio (dB)
>112
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
< 0.01
Max power consumption (W)
N/A
Damping factor
>1100
Dimensions (mm)
432 × 305 × 95
Weight (kg)
12.2
Official link
