McIntosh MSA5500
Image source - (c) McIntosh

The MSA5500 is a two-channel solid-state streaming integrated amplifier from McIntosh Laboratory. In one compact chassis it combines a network music streamer, a preamplifier with moving magnet phono input and a direct-coupled power amplifier rated at 100 W per channel. It is a certified Roon Ready and Roon Tested device and carries a 3-year limited warranty.

Key specs that matter

Power output is 100 W per channel into 8 ohms and 160 W into 4 ohms over 20 Hz - 20 kHz. THD is 0.005% and dynamic headroom 1.8 dB. Frequency response is +0/-0.5 dB from 20 Hz to 20 kHz and +0/-3 dB from 10 Hz to 100 kHz. Damping factor is above 200 at 8 ohms and above 100 at 4 ohms. Sensitivity is 2.5 mV (MM phono), 0.5 V/0.25 V (high level, balanced/unbalanced) and 1 V (power amp input), with 20 kohm input impedance. Signal-to-noise ratio is 82 dB (phono), 95 dB (high level) and 110 dB (power amp input). Physical inputs are one balanced, four unbalanced, one MM phono with fixed loading, two coaxial, two optical, one USB, one MCT and one HDMI ARC. Dimensions are 444.5 x 152 x 476 mm (W x H x D), or 206 mm high with the antennas vertical, and weight is 17.2 kg.

Engineering and use context

Streaming covers Apple AirPlay, Google Cast, Qobuz Connect, Spotify Connect including Spotify Lossless and TIDAL Connect including TIDAL Max, at up to 24-bit/192 kHz over the network. Two Wi-Fi 6 antennas, a Bluetooth antenna and an Ethernet port are provided. Bluetooth 5.0 supports AAC, aptX HD and aptX Adaptive.

Conversion uses an 8-channel 32-bit/384 kHz PCM/DSD DAC in Quad Balanced configuration. Over USB it accepts 32-bit PCM up to 384 kHz, DSD64 to DSD256 and DXD, and the coaxial and optical inputs take up to 24-bit/192 kHz. Through HDMI ARC it plays audio from a compatible TV, with Dolby and DTS multichannel formats converted to two channels.

Power Guard monitors the output signal for overdriving and adjusts the input signal in real time to prevent clipping. Sentry Monitor is a fuse-less short-circuit protection circuit that disengages the output stage and resets automatically. Monogrammed Heatsinks are connected to high-current output transistors, and the gold-plated speaker terminals are patented Solid Cinch binding posts. Its dual-scale blue watt meters sit on a black glass front panel.

Pairing

The internal amplifier can be bypassed for an external power amplifier through the 8 V variable output. A subwoofer output connects a powered subwoofer. The headphone output is a 6.3 mm High Drive jack with Headphone Crossfeed Director.

Alternatives

The McIntosh MA5300 has the same 100 W/160 W rating and the DA1 digital module, without network streaming or HDMI ARC.

Specifications

  • Model name

    MSA5500

  • Type

    N/A

  • Analog inputs (balanced)

    1

  • Analog inputs (single-ended)

    4

  • Input sensitivity (mV)

    N/A

  • Input impedance (balanced) (Ω)

    20000

  • Input impedance (single-ended) (Ω)

    N/A

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • D/A conversion

    N/A

  • Phono MM/MC current-sensing input impedance (Ω)

    N/A

  • Output power (8Ω) (W)

    2 x 100

  • Output power (4Ω) (W)

    2 x 160

  • Gain (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    10

  • Frequency response high +/- 3dB (Hz)

    100000

  • Signal to Noise Ratio (dB)

    110

  • Total Harmonic Distortion + Noise (%)

    0.005

  • Damping factor

    200

  • Dimensions (mm)

    444.5 x 152 x 476

  • Weight (kg)

    17.2
