Integrated amplifiers — McIntosh MA5300

Name: MA5300
Brand: McIntosh
Rating: 100 (1 reviews)

Description, images, technical data and specifications

McIntosh MA5300
Image source — © McIntosh

The amplifier outputs 100 watts per channel at 8 ohms and 160 watts per channel at 4 ohms. The new wattmeters with a double scale, graduated for a load of 8 and 4 ohms, are responsible for the display.

Specifications

Model name
MA5300
Type
Integrated with DAC and Phono
Analog inputs (balanced)
1
Analog inputs (single-ended)
4
Input sensitivity (mV)
1000
Input impedance (balanced) (Ω)
20 000
Input impedance (single-ended) (Ω)
20 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
D/A conversion
Yes
Phono MM/MC current-sensing input impedance (Ω)
N/A
Output power (8Ω) (W)
100
Output power (4Ω) (W)
160
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
10
Frequency response high +/- 3dB (Hz)
100 000
Signal to Noise Ratio (dB)
110
Total Harmonic Distortion + Noise (%)
0.005
Damping factor
>200
Dimensions (mm)
444.5 x 152 x 476
Weight (kg)
17.2
Official link
https://www.mcintoshlabs.com/products/integrated-amplifiers/MA5300
