Integrated amplifiers — Moon by Simaudio 641
Description, images, technical data and specifications
Moon by Simaudio 641
Image source — © Moon by Simaudio
Simaudio Moon 641 is a North Collection integrated amplifier with a power of 2×125 watts (8 ohms), a frequency range of 2 Hz—90 kHz and ultra–low distortion (0.003%). Equipped with an innovative MDCA circuit for noise reduction, dual mono and precise M-VOL3 volume control.
Specifications
Model name
641
Type
Integrated Amplifier
Analog inputs (balanced)
1
Analog inputs (single-ended)
4
Input sensitivity (mV)
300
Input impedance (balanced) (Ω)
22 000
Input impedance (single-ended) (Ω)
22 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
D/A conversion
Yes
Phono MM/MC current-sensing input impedance (Ω)
N/A
Output power (8Ω) (W)
125
Output power (4Ω) (W)
250
Gain (dBu)
37
Frequency response low +/- 3dB (Hz)
2
Frequency response high +/- 3dB (Hz)
90 000
Signal to Noise Ratio (dB)
109
Total Harmonic Distortion + Noise (%)
0,003%
Damping factor
700
Dimensions (mm)
481×102×465
Weight (kg)
26
