Integrated amplifiers — Moon by Simaudio 700i V2

Description, images, technical data and specifications

Moon by Simaudio 700i V2
Image source — © Moon by Simaudio

The 700i V2 is an integrated amplifier with built-in DAC from Moon by Simaudio, a well-established Canadian manufacturer known for accomplished, measurement-focused electronics engineering, built with an exceptional damping factor. The 700i V2 brings Moon's considered engineering to a complete integrated chassis.

Key specs that matter

One balanced XLR input and five single-ended inputs are provided. Input impedance is a substantial 100,000 ohms balanced or 50,000 ohms single-ended. Output power is 175W into 8 ohms, rising to 350W into 4 ohms. Frequency response spans a wide 10Hz to 100,000Hz within plus-or-minus 3dB. Signal-to-noise ratio is an exceptional 120dB, with total harmonic distortion plus noise under an exceptionally low 0.003%. Damping factor is an extraordinary 850 - a remarkable figure indicating exceptional control over loudspeaker cone motion. At 140 x 476 x 460mm and 27kg, the 700i V2 represents a substantial integrated amplifier commitment reflecting Moon's considered Canadian engineering standards.

Sound and use context

Expect exceptionally clean, tightly controlled amplification reflecting the extraordinary 850 damping factor combined with the exceptional 120dB signal-to-noise figure, consistent with Moon's broader measurement-focused engineering philosophy.

Pairing

The extraordinary 850 damping factor suits demanding loudspeaker loads with excellent bass control, and the built-in DAC covers digital sources directly.

Alternatives

Moon's broader integrated amplifier catalogue offers alternatives at different tiers for buyers wanting a different balance of features.

Specifications

  • Model name

    700i V2

  • Type

    Integrated Amplifier with DAC

  • Analog inputs (balanced)

    1

  • Analog inputs (single-ended)

    5

  • Input sensitivity (mV)

    N/A

  • Input impedance (balanced) (Ω)

    100 000

  • Input impedance (single-ended) (Ω)

    50 000

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • D/A conversion

    Yes

  • Phono MM/MC current-sensing input impedance (Ω)

    N/A

  • Output power (8Ω) (W)

    175

  • Output power (4Ω) (W)

    350

  • Gain (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    10

  • Frequency response high +/- 3dB (Hz)

    100 000

  • Signal to Noise Ratio (dB)

    120

  • Total Harmonic Distortion + Noise (%)

    <0.003

  • Damping factor

    850

  • Dimensions (mm)

    140 x 476 x 460

  • Weight (kg)

    27
