Allnic Audio H-10000 OTL/OCL
Image source - © Allnic Audio

The Allnic Audio H-10000 OTL/OCL is a flagship phono stage (a preamplifier/equalizer for vinyl turntables) introduced by the company as part of its absolute "10000 Signature" line of components.

Specifications

  • Model name

    H-10000 OTL/OCL

  • Inputs (balanced)

    N/A

  • Inputs (single-ended)

    4

  • MC current-sensing input impedance (Ω)

    N/A

  • MM/MC voltage input impedance (Ω)

    up to 200 (MC), up to 47 000 (MM)

  • Output impedance (Ω)

    50

  • Gain (dB)

    40 (MM), 72 (MC)

  • Playback EQ curves accuracy (dB)

    N/A

  • Frequency response low +/- 3dB (Hz)

    20

  • Frequency response high +/- 3dB (Hz)

    20 000

  • Total Harmonic Distortion + Noise (%)

    <0.1

  • Dimensions (mm)

    430 x 380 x 200 (Phonostage) + 430 x 330 x 130 (Power supply)

  • Weight (kg)

    12.6 (Phonostage) + 16 (Power supply)

  • Official link

    https://allnicaudio.com/product/h-10000/
