Cartridges — HANA EH MK II

Description, images, technical data and specifications

HANA EH MK II
Image source — © HANA

Hana EH Mk II is aimed at owners of systems without a specialized MC input. With an output voltage of 2 mV and a coil resistance of 130 ohms, the cartridge is designed to connect to a conventional 47 kOhm MM phono input.

Specifications

  • Model name

    EH MK II

  • Type

    MC

  • Stylus

    Synthetic Elliptical

  • Body

    N/A

  • Cantilever

    Aluminum

  • Coils

    N/A

  • Output voltage (mV@5cm/sec)

    2

  • Frequency response low +/- 3dB (Hz)

    15

  • Frequency response high +/- 3dB (Hz)

    25 000

  • Internal impedance (Ohm)

    130

  • Channel separation (dB / 1,000 Hz)

    25

  • Compliance (×10-6cm/dyne at 100Hz)

    N/A

  • Recommended load (Ohm)

    47 000

  • Recommended tonearms

    N/A

  • Weight (g)

    8.6

  • Official link

    https://www.hanacartridges.com/products/hana-eh-mk-ii
