Integrated amplifiers — Allnic Audio T-1800 MK2

Description, images, technical data and specifications

Allnic Audio T-1800 MK2
Image source - © Allnic Audio

The Allnic Audio T-1800 MK2 is an integrated vacuum tube amplifier. It is built around the classic British EL34 output tubes, which lend it a recognizable, musical character-yet it incorporates Allnic’s proprietary technologies, elevating it far beyond the scope of a typical EL34-based amplifier.

Specifications

  • Model name

    T-1800 MK2

  • Type

    Tube Integrated Amplifier

  • Analog inputs (balanced)

    1

  • Analog inputs (single-ended)

    4

  • Input sensitivity (mV)

    400

  • Input impedance (balanced) (Ω)

    10 000

  • Input impedance (single-ended) (Ω)

    10 000

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • D/A conversion

    N/A

  • Phono MM/MC current-sensing input impedance (Ω)

    N/A

  • Output power (8Ω) (W)

    40 + 40

  • Output power (4Ω) (W)

    40 + 40

  • Gain (dBu)

    38

  • Frequency response low +/- 3dB (Hz)

    20

  • Frequency response high +/- 3dB (Hz)

    20 000

  • Signal to Noise Ratio (dB)

    80

  • Total Harmonic Distortion + Noise (%)

    0.1

  • Damping factor

    8 at 8Ω load at 1kHz

  • Dimensions (mm)

    430 x 330 x 210

  • Weight (kg)

    20

  • Official link

    https://allnicaudio.com/product/t-1800/
