Phonostages — Manley STEELHEAD RC
Description, images, technical data and specifications
Manley STEELHEAD RC
Image source — © Manley
The Manley Steelhead RC is a top—of-the-line tube phono corrector/preamp for MM/MC with flexible settings and outstanding musicality.
Specifications
Model name
STEELHEAD RC
Inputs (balanced)
N/A
Inputs (single-ended)
4
MC current-sensing input impedance (Ω)
N/A
MM/MC voltage input impedance (Ω)
25, 50, 100, 200 and 400 (MC), 100, 470, 800, 1000 and 47000 (MM)
Output impedance (Ω)
150
Gain (dB)
50, 55, 60 and 65
Playback EQ curves accuracy (dB)
N/A
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Total Harmonic Distortion + Noise (%)
0.0042
Dimensions (mm)
480 × 105 × 460
Weight (kg)
6.8
