Phonostages — SOtM sPQ-100
Description, images, technical data and specifications
SOtM sPQ-100
Image source — © SOtM
The model is designed for use with pickup heads with a movable magnet (MM) and a movable coil (MS). The nominal input sensitivity for MM is 3 mV, for MS – 0.1 mV.
Specifications
Model name
sPQ-100
Inputs (balanced)
N/A
Inputs (single-ended)
1
MC current-sensing input impedance (Ω)
N/A
MM/MC voltage input impedance (Ω)
MC: 15, 20, 100, 500, MM: 47 000
Output impedance (Ω)
N/A
Gain (dB)
40, 50, 60, 70
Playback EQ curves accuracy (dB)
N/A
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Total Harmonic Distortion + Noise (%)
N/A
Dimensions (mm)
106 x 48 x 245
Weight (kg)
1.5
