AVM AVM30 PH 30.3
Image source — © AVM
The AVM Audio PH 30.3 phono corrector is suitable for amplifying signals from MC as well as MM pickups. In order to perfectly adapt your system to receive the MC signal from PH 30.3, 100/200/1000 Ohm load adapters are included.
Specifications
Model name
AVM30 PH 30.3
Inputs (balanced)
N/A
Inputs (single-ended)
3
MC current-sensing input impedance (Ω)
N/A
MM/MC voltage input impedance (Ω)
47 000
Output impedance (Ω)
47
Gain (dB)
60 (MC) + 40 (MM)
Playback EQ curves accuracy (dB)
N/A
Frequency response low +/- 3dB (Hz)
8
Frequency response high +/- 3dB (Hz)
100 000
Total Harmonic Distortion + Noise (%)
N/A
Dimensions (mm)
150 x 52 x 108
Weight (kg)
0.5
Official link
