Analog Relax EX700
Image source — © Analog Relax

The Analog Relax EX700 head uses a boron cantilever, which provides high response speed, control, and clarity. The coils are wound with high-purity copper wire to add tonal richness and maintain the dynamic integrity of the sound.

Specifications

  • Model name

    EX700

  • Type

    MC

  • Stylus

    Special line contact solid diamond

  • Body

    Finest 'spruce' from the South Tyrol region of Northern Italy, ‘Violin Varnish Finish’

  • Cantilever

    Solid Boron

  • Coils

    High purity copper

  • Output voltage (mV@5cm/sec)

    0.45

  • Frequency response low +/- 3dB (Hz)

    N/A

  • Frequency response high +/- 3dB (Hz)

    N/A

  • Internal impedance (Ohm)

    4.5

  • Channel separation (dB / 1,000 Hz)

    27

  • Compliance (×10-6cm/dyne at 100Hz)

    6μm/mN

  • Recommended load (Ohm)

    N/A

  • Recommended tonearms

    N/A

  • Weight (g)

    10

  • Official link

    https://analogrelax.com/en/product/ex700/
