ONIX Zenith XDA20
Image source — © ONIX
ONIX Zenith XDA20 uses the developments of the famous ONIX Miracle System – the heart of the DAC is also the ESS Technology ES9039Pro chip, only in the case of ONIX Zenith XDA20, two converters are installed. Together with eight operational amplifiers TI OPA1611 from Texas Instruments in its own I/V circuit, this solution offers exceptional accuracy and decoding of signals up to PCM with parameters up to 32/768 and DSD up to DSD512.
Specifications
Model name
Zenith XDA20
Conversion type
N/A
Engine
ESS Technology ES9039Pro x 2
DSD compatability
Yes
Parameters
up yo PCM 32/768 and DSD512
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
40000
Gain (dBu)
N/A
Output Level (balanced) (V)
4.2
Output Level (single-ended) (V)
N/A
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
N/A
Output Impedance (single-ended) (Ω)
N/A
Analog outputs
N/A
Signal to Noise Ratio (dB)
127
Total Harmonic Distortion + Noise (% at 22 kHz)
0.0003
Dimensions (mm)
320 x 240 x 62
Weight (kg)
5.7
