DACs — iFi Audio ZEN Air DAC 2
Description, images, technical data and specifications
iFi Audio ZEN Air DAC 2
Image source — © iFi Audio
iFi Audio ZEN Air DAC 2 is a USB DAC and headphone amplifier from the ZEN Air line. It is equipped with a Cirrus Logic DAC, balanced output of 4,4 mm and an unbalanced connection. The output power has been increased by 300% relative to the previous version. Supports 384 kHz PCM and DSD256. It has XBass+ (woofer gain) and PowerMatch (+6 dB gain) functions. Designed for compact audio systems.
Specifications
Model name
ZEN Air DAC 2
Conversion type
N/A
Engine
N/A
DSD compatability
Yes
Parameters
up to PCM 384kHz and DSD256
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
90 000
Gain (dBu)
N/A
Output Level (balanced) (V)
N/A
Output Level (single-ended) (V)
N/A
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
N/A
Output Impedance (single-ended) (Ω)
50
Analog outputs
N/A
Signal to Noise Ratio (dB)
118
Total Harmonic Distortion + Noise (% at 22 kHz)
≤0.0011
Dimensions (mm)
158 x 100 x 35
Weight (kg)
0.315
Official link
