DACs — Canor Audio Verto D4S
Description, images, technical data and specifications
Canor Audio Verto D4S
Image source — © Canor Audio
The Canor Verto D4S digital-to-analog converter is based on two Sabre ES9038 chips from ESS Technology, operating in a dual mono configuration, which allows for a wide dynamic range and exceptionally low noise levels. The analog output stage of the component is completely discrete. Canor Audio engineers have fundamentally abandoned operational amplifiers in the signal path.
Specifications
Model name
Verto D4S
Conversion type
N/A
Engine
2 x ESS9038Q2M
DSD compatability
Yes
Parameters
up to 24-bit / 768 kHz and DSD512
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Gain (dBu)
N/A
Output Level (balanced) (V)
4
Output Level (single-ended) (V)
2
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
200
Output Impedance (single-ended) (Ω)
100
Analog outputs
N/A
Signal to Noise Ratio (dB)
> 112
Total Harmonic Distortion + Noise (% at 22 kHz)
< 0.0005
Dimensions (mm)
430 x 75 x 300
Weight (kg)
8
Official link
