SOtM sDP-1000EX
Image source — © SOtM

The SotM sDP-1000EX is a high-end DAC and preamp with support for PCM up to 32 bit/384 kHz and DSD up to DSD128, as well as asynchronous USB input for maximum digital audio quality.

Specifications

  • Model name

    sDP-1000EX

  • Conversion type

    N/A

  • Engine

    N/A

  • DSD compatability

    Yes

  • Parameters

    up to 32 bit/384KHz and DSD128

  • Frequency response low +/- 3dB (Hz)

    20

  • Frequency response high +/- 3dB (Hz)

    20 000

  • Gain (dBu)

    N/A

  • Output Level (balanced) (V)

    3.8

  • Output Level (single-ended) (V)

    3.8

  • Input Impedance (balanced) (Ω)

    10 000

  • Input Impedance (single-ended) (Ω)

    10 000

  • Output Impedance (balanced) (Ω)

    47

  • Output Impedance (single-ended) (Ω)

    47

  • Analog outputs

    N/A

  • Signal to Noise Ratio (dB)

    N/A

  • Total Harmonic Distortion + Noise (% at 22 kHz)

    < 0.003

  • Dimensions (mm)

    360 x 68 x 245

  • Weight (kg)

    4

  • Official link

    https://www.sotm-audio.com/sotmwp/english/portfolio-item/sdp-1000/
