DACs — Esoteric N-01XE
Description, images, technical data and specifications
Esoteric N-01XE
Image source — © Esoteric
The Grandioso N1 features a discrete Master Sound Discrete DAC G2, a fourth‑generation Network Engine G4, and fully separate power supply for digital and analog components.
Specifications
Model name
N-01XE
Conversion type
N/A
Engine
N/A
DSD compatability
Yes
Parameters
up to 32 bit / 768 kHz and DSD 22.5MHz
Frequency response low +/- 3dB (Hz)
5
Frequency response high +/- 3dB (Hz)
30 000
Gain (dBu)
N/A
Output Level (balanced) (V)
N/A
Output Level (single-ended) (V)
N/A
Input Impedance (balanced) (Ω)
110
Input Impedance (single-ended) (Ω)
75
Output Impedance (balanced) (Ω)
60
Output Impedance (single-ended) (Ω)
20
Analog outputs
N/A
Signal to Noise Ratio (dB)
113
Total Harmonic Distortion + Noise (% at 22 kHz)
0.001
Dimensions (mm)
445 × 161.5 × 437
Weight (kg)
25.7
