DACs — Laiv Audio Harmony DAC 2
Description, images, technical data and specifications
Laiv Audio Harmony DAC 2
Image source — © Laiv Audio
The Harmony DAC 2 is equipped with a direct input for an external 10 MHz clock signal, so no DDC is required to connect the reference clock. Other changes include digital isolation, a 12-volt trigger, a color LCD display, and the ability to update firmware via USB-C. LAiV plans to release an upgrade kit for owners of the previous version of the Harmony DAC, which will add some of the features of the new model.
Specifications
Model name
Harmony DAC 2
Conversion type
N/A
Engine
N/A
DSD compatability
Yes
Parameters
up to PCM 768 кГц · DSD256
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Gain (dBu)
N/A
Output Level (balanced) (V)
4.15
Output Level (single-ended) (V)
2.05
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
50
Output Impedance (single-ended) (Ω)
25
Analog outputs
N/A
Signal to Noise Ratio (dB)
125
Total Harmonic Distortion + Noise (% at 22 kHz)
0.0035
Dimensions (mm)
255 × 250 × 50
Weight (kg)
75 with spikes
Official link
