DACs — Schiit Audio Gungnir 2

Description, images, technical data and specifications

Schiit Audio Gungnir 2
Image source — © Schiit Audio

The Schiit Audio Gungnir 2 DAC expands on Schiit Audio’s multi-bit approach. It uses a new balanced analog stage and four medical/defense-grade DAC8812CRUZ converters with a proprietary time- and frequency-domain-optimized digital filter (based on an Analog Devices DSP). It can be user-switched to operate in a no-oversampling (NOS) mode to bypass the digital filter. The Schiit Audio Gungnir 2 accepts up to 32-bit/384 kHz PCM signals with upscaling and DXD formats. The modular design allows for swappable analog blocks, while Forkbeard support facilitates system-wide control and monitoring via an iOS app.

Specifications

  • Model name

    Gungnir 2

  • Conversion type

    Schiit Multiform

  • Engine

    4 x Texas Instruments DAC8812C

  • DSD compatability

    N/A

  • Parameters

    up to PCM 32/384

  • Frequency response low +/- 3dB (Hz)

    20

  • Frequency response high +/- 3dB (Hz)

    20000

  • Gain (dBu)

    N/A

  • Output Level (balanced) (V)

    N/A

  • Output Level (single-ended) (V)

    N/A

  • Input Impedance (balanced) (Ω)

    N/A

  • Input Impedance (single-ended) (Ω)

    N/A

  • Output Impedance (balanced) (Ω)

    75

  • Output Impedance (single-ended) (Ω)

    75

  • Analog outputs

    N/A

  • Signal to Noise Ratio (dB)

    112

  • Total Harmonic Distortion + Noise (% at 22 kHz)

    0.0008

  • Dimensions (mm)

    40.64 x 20.32 x 5.08

  • Weight (kg)

    5.47

  • Official link

    https://www.schiit.com/products/gungnir-2
