DACs — Eversolo DMP-A10
Description, images, technical data and specifications
Eversolo DMP-A10
Image source - (c) Eversolo
The Eversolo DMP-A10 is a streamer, DAC and preamplifier in one box, and its conversion is done by the ESS ES9039PRO chip. The chip is combined with Eversolo's own streaming and connectivity features.
Key specs that matter
The DMP-A10 plays PCM up to 32-bit/768kHz and DSD up to DSD512, which covers practically any high-resolution file format in a modern digital library. Frequency response is 20Hz to 20,000Hz within plus or minus 3dB. Output level reaches 4.2V from the balanced outputs and 2.1V from the single-ended ones. Eversolo specifies 129-130dB for signal-to-noise. THD plus noise, measured at 22kHz, is 0.000078-0.00009%.
Pairing
As a preamplifier with a 4.2V balanced output, the DMP-A10 can be wired directly into a power amplifier input or into active loudspeakers, so no extra preamp stage is needed.
Alternatives
The Eversolo DAC-Z10 is another DAC from the brand.
Key specs that matter
The DMP-A10 plays PCM up to 32-bit/768kHz and DSD up to DSD512, which covers practically any high-resolution file format in a modern digital library. Frequency response is 20Hz to 20,000Hz within plus or minus 3dB. Output level reaches 4.2V from the balanced outputs and 2.1V from the single-ended ones. Eversolo specifies 129-130dB for signal-to-noise. THD plus noise, measured at 22kHz, is 0.000078-0.00009%.
Pairing
As a preamplifier with a 4.2V balanced output, the DMP-A10 can be wired directly into a power amplifier input or into active loudspeakers, so no extra preamp stage is needed.
Alternatives
The Eversolo DAC-Z10 is another DAC from the brand.
Specifications
Model name
DMP-A10
Conversion type
N/A
Engine
ES9039 Pro
DSD compatability
Yes
Parameters
up to PCM 32/768 and DSD512
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20000
Gain (dBu)
N/A
Output Level (balanced) (V)
4.2
Output Level (single-ended) (V)
2.1
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
N/A
Output Impedance (single-ended) (Ω)
N/A
Analog outputs
N/A
Signal to Noise Ratio (dB)
130 - 129
Total Harmonic Distortion + Noise (% at 22 kHz)
0.000078 - 0.00009
Dimensions (mm)
N/A
Weight (kg)
N/A
Official link
