DACs — YBA DESIGN WD202 DAC
Description, images, technical data and specifications
YBA DESIGN WD202 DAC
Image source — © YBA
The external YBA WD202 DAC, like the WM202 player, is equipped with Texas Instruments PCM1796. The back panel of the device contains all the necessary connectors for switching with most of the possible equipment. So, YBA engineers have provided inputs – optical Toslink, digital coaxial, USB (type B), AES/EBU (digital XLR); outputs – XLR, RCA and digital coaxial.
Specifications
Model name
DESIGN WD202 DAC
Conversion type
N/A
Engine
N/A
DSD compatability
Yes
Parameters
up to 24 bits / 384 kHz and DSD128
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Gain (dBu)
N/A
Output Level (balanced) (V)
2
Output Level (single-ended) (V)
4
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
N/A
Output Impedance (single-ended) (Ω)
N/A
Analog outputs
N/A
Signal to Noise Ratio (dB)
108
Total Harmonic Distortion + Noise (% at 22 kHz)
<0.002
Dimensions (mm)
320 x 280 x 62
Weight (kg)
3.5
