Musician Audio Delphinus
Image source — © Musician Audio
The Musician Delphinus external DAC is based on a discrete R-2R resistor network assembled using resistors with a declared accuracy of 0.005%. A separate conversion path is provided for DSD signals, so PCM and DSD are processed by different sections of the circuit. The user can choose between OS and NOS modes, enable a fast or slow digital filter, and invert the phase.
Specifications
Model name
Delphinus
Conversion type
R-2R
Engine
N/A
DSD compatability
Yes
Parameters
up to 32 bit/1 536 kHz и DSD1024
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
75 000
Gain (dBu)
N/A
Output Level (balanced) (V)
4
Output Level (single-ended) (V)
2
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
1250
Output Impedance (single-ended) (Ω)
625
Analog outputs
N/A
Signal to Noise Ratio (dB)
120
Total Harmonic Distortion + Noise (% at 22 kHz)
0.002
Dimensions (mm)
200 x 195 x 45
Weight (kg)
2.35
