Weiss Engineering DAC204 MK2
Image source — © Weiss Engineering
The main update of the Weiss DAC204-MK2 is a completely redesigned DAC board. Instead of the previous solution, the Sabre ES9028PRO chip from ESS Technology is used, and the architecture itself is complemented by an improved jitter suppression system. According to the manufacturer, this should increase the stability of the conversion even when working with sources where the jitter level may be higher than optimal. Serious attention is also paid to the analog output stage.
Specifications
Model name
DAC204 MK2
Conversion type
N/A
Engine
N/A
DSD compatability
Yes
Parameters
up to 24 bit / 384 kHz and DSD128
Frequency response low +/- 3dB (Hz)
0
Frequency response high +/- 3dB (Hz)
80 000
Gain (dBu)
N/A
Output Level (balanced) (V)
7.5
Output Level (single-ended) (V)
3.75
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
N/A
Output Impedance (single-ended) (Ω)
N/A
Analog outputs
N/A
Signal to Noise Ratio (dB)
N/A
Total Harmonic Distortion + Noise (% at 22 kHz)
0.00016
Dimensions (mm)
165 x 105 x 95
Weight (kg)
N/A
