CD / SACD players and transports — YBA PASSION CD430

Description, images, technical data and specifications

YBA PASSION CD430
Image source — © YBA

The CD430 has always been a very important part of our Passion line, so we had to pay special attention to it when upgrading to the MKII version. The transition from the discontinued Philips CD PRO mechanics to the Philips CDM4 and the upgrade of the DAC section to a pair of AD1955 analog devices ensured that the original sound quality was preserved and makes it look forward to the future.

What is it?

Ask AI to scan specialized sites and forums, evaluate the impressions of using the product, its advantages and disadvantages and get a summary.

Specifications

  • Model name

    PASSION CD430

  • Transport

    Yes

  • Player

    Yes

  • SACD support

    N/A

  • Engine

    N/A

  • Frequency response low +/- 3dB (for CD) (Hz)

    20

  • Frequency response high +/- 3dB (for CD) (Hz)

    20 000

  • Frequency response low +/- 3dB (for SACD) (Hz)

    N/A

  • Frequency response high +/- 3dB (for SACD) (Hz)

    N/A

  • Gain (dBu)

    N/A

  • Output Level (balanced) (V)

    2.3

  • Output Level (single-ended) (V)

    4.6

  • Input Impedance (balanced) (Ω)

    N/A

  • Input Impedance (single-ended) (Ω)

    N/A

  • Output Impedance (balanced) (Ω)

    N/A

  • Output Impedance (single-ended) (Ω)

    N/A

  • Dynamic range (for CD) (dB)

    N/A

  • Dynamic range (for SACD) (dB)

    N/A

  • Signal to Noise Ratio (for CD) (dB)

    110

  • Signal to Noise Ratio (for SACD) (dB)

    N/A

  • Total Harmonic Distortion + Noise (for CD) (%)

    0.0015% (16bit), 0.0008% (24bit)

  • Total Harmonic Distortion + Noise (for SACD) (%)

    N/A

  • Dimensions (mm)

    430 x 388 x 118

  • Weight (kg)

    12.8

  • Official link

    https://www.ybahifi.com/product/passion-cd4-cd430-cd-player/
