Headphones amplifiers — Lehmann Audio Drachenfels

Specifications

• Model name

  Drachenfels

• Maximum Power, 32 Ohms (mW RMS per channel)

  180 (33 Ohms)

• Maximum Power, 50 Ohms (mW RMS per channel)

  N/A

• Maximum Power, 300 Ohms (mW RMS per channel)

  110 (330 Omhs)

• Maximum Power, 600 Ohms (mW RMS per channel)

  N/A

• Frequency response low +/- 3dB (Hz)

  10

• Frequency response high +/- 3dB (Hz)

  35 000

• Gain (dBu)

  12

• THD (% at 1V RMS, 300 ohms)

  < 0,006

• Signal to Noise Ratio (dB)

  >85

• IMD (%, CCIR, 300 Ohms)

  N/A

• Crosstalk (dB, 20Hz-20KHz, 300 Ohms)

  N/A

• Output Impedance (Ohms)

  pre-out: 105, phones out: 5

• Dimensions (mm)

  160 x 120 x 43

• Weight (kg)

  0.5

• Official link

  https://www.lehmannaudio.com/headphone-amplifiers/home/drachenfels.html
