Preamplifiers — Rotel RC-1572MKII

Specifications

• Model name

  RC-1572MKII

• Analog inputs (balanced)

  1

• Analog inputs (single-ended)

  4

• Analog outputs (balanced)

  1

• Analog outputs (single-ended)

  1

• Gain (dBu)

  N/A

• Input sensitivity (mV)

  300 (XLR) + 200 (RCA) + 3 (Phono)

• Output voltage (V)

  2 (XLR) + 1 (RCA)

• Input impedance (balanced) (Ω)

  100 000

• Input impedance (single-ended) (Ω)

  100 000 + 47 000 (Phono)

• Output impedance (balanced) (Ω)

  N/A

• Output impedance (single-ended) (Ω)

  N/A

• Maximum output level (balanced) (dBu)

  N/A

• Maximum output level (single-ended) (dBu)

  N/A

• Volume control range (dBu)

  N/A

• Frequency response low +/- 3dB (Hz)

  20

• Frequency response high +/- 3dB (Hz)

  20 000

• Signal to Noise Ratio (SNR, unweighted) (dB)

  118 + 80 (Phono)

• Total Harmonic Distortion + Noise (THD+N) (%)

  <0.004

• Dimensions (mm)

  431 × 99 × 338

• Weight (kg)

  8.4

• Official link

  https://rotel.com/product/rc-1572mkii
