Preamplifiers — Rotel Michi P5 Series 2

Description, images, technical data and specifications

Rotel Michi P5 Series 2
Image source — © Rotel

The digital part includes a DAC on ARM chips from Asahi Kasei with 32-bit/768 kHz parameters, capable of working with MCU files and supporting DSD and DOP streams. There is also a universal MM/MS phono corrector on board. As for the physical connectors, they include a full set of analog RCA and XLR inputs and outputs, as well as digital inputs – optical, coaxial and USB. The latter support streams with a bit depth of up to 32 bits and a sampling rate of up to 384 kHz.

Specifications

  • Model name

    Michi P5 Series 2

  • Analog inputs (balanced)

    1

  • Analog inputs (single-ended)

    4 + 1 (Phono)

  • Analog outputs (balanced)

    2

  • Analog outputs (single-ended)

    2

  • Gain (dBu)

    N/A

  • Input sensitivity (mV)

    N/A

  • Output voltage (V)

    N/A

  • Input impedance (balanced) (Ω)

    100 000

  • Input impedance (single-ended) (Ω)

    47 000

  • Output impedance (balanced) (Ω)

    100

  • Output impedance (single-ended) (Ω)

    470

  • Maximum output level (balanced) (dBu)

    2

  • Maximum output level (single-ended) (dBu)

    1

  • Volume control range (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    20

  • Frequency response high +/- 3dB (Hz)

    200 000

  • Signal to Noise Ratio (SNR, unweighted) (dB)

    116

  • Total Harmonic Distortion + Noise (THD+N) (%)

    <0.002

  • Dimensions (mm)

    485 × 150 × 452

  • Weight (kg)

    22.9

  • Official link

    https://rotel.com/product/p5-series-2

Rotel Michi P5
