Preamplifiers — Parasound JC2BP
Description, images, technical data and specifications
Parasound JC2BP
Image source — © Parasound
The designers abandoned the conventional toroidal mains transformer in favor of an R-type core transformer, which practically eliminates its own interference radiation, and also used separate power sources for audio circuits and relay windings. Even the control triggers and mode indication LEDs are powered separately. Balanced inputs and outputs, switchable polarity of unbalanced outputs, fully remote control – this is not a complete list of properties of Parasound JC2BP.
Specifications
Model name
JC2BP
Analog inputs (balanced)
2
Analog inputs (single-ended)
6
Analog outputs (balanced)
1
Analog outputs (single-ended)
3
Gain (dBu)
14
Input sensitivity (mV)
200
Output voltage (V)
N/A
Input impedance (balanced) (Ω)
30 000
Input impedance (single-ended) (Ω)
30 000
Output impedance (balanced) (Ω)
60
Output impedance (single-ended) (Ω)
60
Maximum output level (balanced) (dBu)
N/A
Maximum output level (single-ended) (dBu)
N/A
Volume control range (dBu)
N/A
Frequency response low +/- 3dB (Hz)
5
Frequency response high +/- 3dB (Hz)
100 000
Signal to Noise Ratio (SNR, unweighted) (dB)
>116
Total Harmonic Distortion + Noise (THD+N) (%)
< 0.003 at 100 Hz
Dimensions (mm)
437 × 406 × 150
Weight (kg)
11
Official link
