Preamplifiers — YBA GENESIS PRE5A
Description, images, technical data and specifications
YBA GENESIS PRE5A
Image source — © YBA
The PRE5 preamp uses the most advanced Bluetooth standards that support the aptX audio transmission protocol. Bluetooth is not all that the PRE5 has to offer, the preamp allows you to use up to 8 different signal source connection options. The PRE 5 is also equipped with a high-end built-in DAC, which allows you to decode the signal via: AES/EBU, Optical, Coaxial, BNC, USB and Bluetooth.
Specifications
Model name
GENESIS PRE5A
Analog inputs (balanced)
1
Analog inputs (single-ended)
2
Analog outputs (balanced)
1
Analog outputs (single-ended)
2
Gain (dBu)
6
Input sensitivity (mV)
N/A
Output voltage (V)
N/A
Input impedance (balanced) (Ω)
N/A
Input impedance (single-ended) (Ω)
N/A
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Maximum output level (balanced) (dBu)
N/A
Maximum output level (single-ended) (dBu)
N/A
Volume control range (dBu)
N/A
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Signal to Noise Ratio (SNR, unweighted) (dB)
>105
Total Harmonic Distortion + Noise (THD+N) (%)
<0.003
Dimensions (mm)
430 x 388 x 115
Weight (kg)
10
Official link
