Preamplifiers — Kondo Audio Note Japan G-1000i
Description, images, technical data and specifications
Kondo Audio Note Japan G-1000i
Image source — © Kondo Audio Note Japan
Specifications
Model name
G-1000i
Analog inputs (balanced)
1
Analog inputs (single-ended)
4
Analog outputs (balanced)
1
Analog outputs (single-ended)
2
Gain (dBu)
25
Input sensitivity (mV)
N/A
Output voltage (V)
N/A
Input impedance (balanced) (Ω)
50 000
Input impedance (single-ended) (Ω)
50 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
20 000
Maximum output level (balanced) (dBu)
N/A
Maximum output level (single-ended) (dBu)
N/A
Volume control range (dBu)
N/A
Frequency response low +/- 3dB (Hz)
10
Frequency response high +/- 3dB (Hz)
280 000
Signal to Noise Ratio (SNR, unweighted) (dB)
N/A
Total Harmonic Distortion + Noise (THD+N) (%)
N/A
Dimensions (mm)
320 x 160 x 414 (main) + 320 x 160 x 414 (PSU)
Weight (kg)
17 (main) + 20 (PSU)
Official link
