Power amplifiers stereo — SMSL VMV A1 Pro

Description, images, technical data and specifications

SMSL VMV A1 Pro
Image source — © SMSL

The SMSL VMV A1 Pro takes advantage of this with a switching frequency of up to 1 MHz — far exceeding the typical 300-500 kHz frequency used in conventional Class D amplifiers.

Specifications

  • Model name

    VMV A1 Pro

  • Input sensitivity (mV)

    680

  • Input impedance (balanced) (Ω)

    N/A

  • Input impedance (single-ended) (Ω)

    N/A

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • Max current (A)

    N/A

  • Output power (8Ω) (W)

    85

  • Output power (4Ω) (W)

    160

  • Gain (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    N/A

  • Frequency response high +/- 3dB (Hz)

    N/A

  • Signal to Noise Ratio (dB)

    109

  • Total Harmonic Distortion + Noise (0% global feedback) (%)

    N/A

  • Total Harmonic Distortion + Noise (100% global feedback) (%)

    0.003

  • Max power consumption (W)

    40

  • Damping factor

    N/A

  • Dimensions (mm)

    210 × 47.6 × 201.6

  • Weight (kg)

    1.56

  • Official link

    https://www.smsl-audio.com/portal/product/detail/id/911.html
