Power amplifiers stereo — Gryphon Audio Mephisto Stereo

Description, images, technical data and specifications

Gryphon Audio Mephisto Stereo
Image source — © Gryphon Audio

The output section of Gryphon Mephisto Stereo uses Sanken bipolar transistors which can to deliver momentary peak power of 4,000 watts per channel with-out overload! Gryphon Audio uses original scheme - each of the 40 transistors is bypassed with individual film capacitors and the driver section has its own supply based on the custom-made toroidal transformers. The capacitors are divided into two sections – diver section has 50.000 uF of ultra-fast capacitance, power capacitor bank has big 500,000 uF array. Of course there us no negative feedback employed.

Specifications

  • Model name

    Mephisto Stereo

  • Input sensitivity (mV)

    N/A

  • Input impedance (balanced) (Ω)

    N/A

  • Input impedance (single-ended) (Ω)

    N/A

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • Max current (A)

    N/A

  • Output power (8Ω) (W)

    2 x 200

  • Output power (4Ω) (W)

    N/A

  • Gain (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    0

  • Frequency response high +/- 3dB (Hz)

    350000

  • Signal to Noise Ratio (dB)

    N/A

  • Total Harmonic Distortion + Noise (0% global feedback) (%)

    0.006

  • Total Harmonic Distortion + Noise (100% global feedback) (%)

    N/A

  • Max power consumption (W)

    N/A

  • Damping factor

    N/A

  • Dimensions (mm)

    520 x 430 x 710

  • Weight (kg)

    111.13

  • Official link

    https://gryphon-audio.dk/the-collection/power-amplifiers/mephisto/
