Power amplifiers stereo — Parasound JC5

Description, images, technical data and specifications

Parasound JC5
Image source — © Parasound

The Parasound JC5 power amplifier is based on the concept of the JC 1 monoblock. The device outputs up to 400 watts per channel at 8 ohms, 600 watts at 4 ohms and as much as 1200 watts/8 ohms in bridge mono mode.As the manufacturer explains, the Halo JC 5 was created for the company's customers who loved the Halo JC 1 monoblock amplifier. The new model has become a more affordable and compact extension of the JC 1.

Specifications

  • Model name

    JC5

  • Input sensitivity (mV)

    1000

  • Input impedance (balanced) (Ω)

    66 000

  • Input impedance (single-ended) (Ω)

    33 000

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • Max current (A)

    N/A

  • Output power (8Ω) (W)

    400

  • Output power (4Ω) (W)

    600

  • Gain (dBu)

    29

  • Frequency response low +/- 3dB (Hz)

    5

  • Frequency response high +/- 3dB (Hz)

    100 000

  • Signal to Noise Ratio (dB)

    N/A

  • Total Harmonic Distortion + Noise (0% global feedback) (%)

    N/A

  • Total Harmonic Distortion + Noise (100% global feedback) (%)

    < 0.05

  • Max power consumption (W)

    N/A

  • Damping factor

    1000

  • Dimensions (mm)

    448 × 181 × 197

  • Weight (kg)

    33.1

  • Official link

    https://parasound.com/products/jc5
