Power amplifiers stereo — Gato Audio DPA-4004
Description, images, technical data and specifications
Gato Audio DPA-4004
Image source — © Gato Audio
The Gato Audio DPA-4004 four-channel amplifier is a flexible solution offering a variety of options for combining the number of channels and output power. A special feature of the amplifier is the use of modern technology for building Class-D output stages, which, combined with bridging channels, makes it possible to obtain high output power with such a compact and elegant housing.
Specifications
Model name
DPA-4004
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
40 000
Input impedance (single-ended) (Ω)
20 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
800
Output power (4Ω) (W)
1600
Gain (dBu)
26
Frequency response low +/- 3dB (Hz)
2
Frequency response high +/- 3dB (Hz)
70 000
Signal to Noise Ratio (dB)
>110
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
< 0,01
Max power consumption (W)
N/A
Damping factor
N/A
Dimensions (mm)
325 x 105 x 420
Weight (kg)
13
