Power amplifiers stereo — Ati (Audio Technologies Inc.) AT6012
Description, images, technical data and specifications
Ati (Audio Technologies Inc.) AT6012
Image source — © Ati (Audio Technologies Inc.)
The AT6012 provides sound quality far superior to that obtained using conventional wall-mounted regulators. Add six up/down keys, a CD player, and speakers, and you have a complete multiroom system with sound quality equal to or even superior to any expensive multiroom system on the market.
Specifications
Model name
AT6012
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
N/A
Input impedance (single-ended) (Ω)
28 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
90
Output power (4Ω) (W)
90
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Signal to Noise Ratio (dB)
120
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
<0.005
Max power consumption (W)
N/A
Damping factor
400
Dimensions (mm)
432 х 178 х 406
Weight (kg)
33.2
Official link
